Lessons Learned from Poor Data Warehouse Design

It’s often said that the best way to learn is from your mistakes, but mistakes made in a data warehouse/business intelligence (BI) environment tend to be very expensive and possibly career-killers. Building a data warehouse isn’t a simple task; it takes a village to build one out of which you can extract viable information.

A data warehouse and the operations that build and maintain it are a combination of business considerations and design best practices. It can be a huge challenge to balance these requirements and still be able to deliver valuable content to users at the end of the day. Make no mistake—not everyone is suited to work in a data warehouse environment, but the work is stimulating and the rewards are satisfying. Here are some of the lessons I’ve learned from designing data warehouses and BI environments.

Get Buy-in from Business and Technical Groups

When designing a data warehouse, business alignment must come first because if the product that’s delivered at the end of the day doesn’t reflect the goals and purposes of the enterprise or meet users’ needs, then the data warehouse is a failure. To give your data warehouse/BI project any chance of success you need to get buy-in from the business and technical sides of your organization, from the top-level executives to the front-line worker bees. Don’t believe that “if you build it they will come.” An IT-driven, IT-sponsored, IT-centric data warehouse/BI project is leaving out the most important facet of a BI solution—alignment to business needs and requirements. Involving business decision makers throughout the project ensures that the data warehouse will deliver meaningful, useful information to business users.

At the beginning of your data warehouse project, establish a steering committee that’s composed of both business decision makers and technical decision makers, and consider establishing a BI competency group that reports to a non-technical C-level manager, such as the COO or CFO. Use these people as a resource throughout the lifetime of the project and even once the system is in production.

Maintain Data Integrity

When designing your data warehouse environment, it’s important to minimize data replication in the table design (by using conformed dimensions, for example) and data inconsistency by vetting source data and adhering to Master Data Management (MDM) standards. (For more information about MDM, see "Master Data Management," January 2007, or "Master Data Management Challenges.")

Poor data quality is one of the biggest hurdles when it comes to data warehouse adoption rates. You can do the following to mitigate poor data quality:

Provide User-Friendly Interfaces

Strive for user-friendly interfaces because a data warehouse without users is a failure, and a BI system that’s too complicated to learn and incorporate into everyday use is a disaster. Providing highly summarized visual information to the business decision makers is one of the things that every data warehouse/BI system must be able to do. Dashboards, which are highly visual real-time reflections of operational activities, and balanced scorecards, which are non-real-time reports that blend the operational, marketing, developmental, and financial aspects of an organization, are both highly summarized and symbolic of a data warehouse. However, without an overarching strategy, dashboards and balanced scorecards can easily become flashy facades for silo-specific “islands of influence” that aren’t connected to enterprise objectives.

To avoid these islands of influence, get your strategy map in place. A strategy map links the long-term goals and objectives of an enterprise with its operational activities, illustrating the cause-and-effect relationship between different Key Performance Indicators (KPIs) that you’ll see on a balanced scorecard and possibly on dashboards. Then, make reports as visual as possible—a picture is truly worth 1000 words.

Reduce Operational Costs

It’s important to make your data warehouse environment easy and cost-effective to support and maintain. Design implementation costs can quickly get out of control. It’s not unusual to have an 80 percent/20 percent division in cost between the back-end ETL and table building processes and the front-end applications and reports. Reduce design implementation costs by creating a set of reusable designs and repeatable ETL processes so that you don’t have to start each data warehouse/BI project with a clean slate. Simplify the design by conforming dimensions and standardizing the granularity of the fact tables wherever possible; do not over-engineer the tables. Overly complex designs can quickly drive costs to the point where the entire project fails.

Make Your Data Warehouse Scalable

Your business is going to change over time, so you need to make sure your data warehouse/BI environment can, too. According to the Gartner Group (Gartner RAS Core Research Note G00161231, James Richardson & Bill Hostmann, 12 September 2008), during the first year of a data warehouse/BI implementation, you should expect users to request changes that will affect 35 percent to 50 percent of the application functions. Anticipating and managing change will be one of your biggest challenges. A good change-enhancement request system should be at the top of your wish-list so that you can better manage the changes that are inevitable with a data warehouse/BI implementation.

In addition, hardware and software costs need to be balanced with scalability. The enterprise will change and so will your data warehouse/BI environment. If the data warehouse isn’t a core competency or the primary line of business, then you should seriously consider running your data warehouse in the cloud. At the time of this writing, Microsoft doesn’t have a viable cloud computing solution for large systems, but there are other options available, including GoGrid, Amazon/Pentaho, and VMware’s newly-released vSphere 4 cloud OS. With the right choice of cloud vendor, you can end up hiring expertise in business continuity, system availability and security, data storage and archiving, and scaling the data warehouse/BI environment as needed, all for a pay-as-you-go price that generally equates to one or two magnitudes decrease in implementation and maintenance costs compared with doing it yourself. Your time-to-terabyte will be measured in days rather than weeks or months.

Comply with Internal and External Standards

Having an enterprise overview of how and where data is used makes figuring out if you’re in compliance much easier. Compliance is another instance in which MDM becomes a “must-have” component in your organization. Although complying with both internal and external standards seems like a big headache prior to a security breach or event, you’ll be glad you did in the event of an attack. Every organization has de-centralized data management, so I recommend using compliance regulations such as Sarbanes-Oxley to level the playing field. An outside influencer can often do more to predicate cooperation than internal directives. Measuring compliance can be a tough and time-consuming job, so you might want to look into risk management software such as RiskWatch, which was originally built to track HIPAA compliance but now includes features that evaluate total enterprise risk.

Data Warehouse Design Tips

It’s not possible to describe or even list all the technical design issues that one could encounter when building a data warehouse. However, the following are some data warehouse design tips that can help you minimize problems in your data warehouse:

Data Warehouse Design Best Practices

There are so many lessons still to be learned about designing data warehouses. From these lessons we glean both business and technical best practices. As you discover new, and possibly better, ways to perform these tasks, spread the wealth by sharing your solutions with your peers.
